foton ROWOR 10 ton tipper truck

FOB Reference Price:Get Latest Price
$60,000.00 - $80,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Drive Wheel:
4x2
Capacity (Load):
1 - 10t
Horsepower:
150 - 250hp
Condition:
New
Transmission Type:
Manual
Emission Standard:
Euro 4
Fuel Type:
Diesel
Engine Capacity:
6 - 8L
Gross Vehicle Weight:
16000
Place of Origin:
Hubei, China
Brand Name:
FOTON
Model Number:
BJ3165DJPHA-1
Dimensions (L x W x H) (mm):
7265*2495*3060mm
color:
green
sideboard:
3mm
baseboard:
4mm
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude with wax, large size transported by RO-RO ship or Bulk ship,small size can be put into a 20GP,40GP or 40HQ.
Port
shanghai
Lead Time :
30 working days



foton ROWOR 10 ton tipper truck

Our company is a professional DUMP TRUCK manufacturer for 10 years.

Our trucks with 3C,ISO,SGS,BV approved.

Chassis supply:DONGFENG,SINOTRUCK,HINO,FOTON,C&C,CAMC,FAW,SHACMAN,

                         IVECO,NISSAN DIESEL,OPTION IS OPTIONAL.

Any questions,contact me without hesitation on 135-9782-6887.





Product functional features of foton ROWOR 10 ton tipper truck

carriage structure:ordinary rectangular and mine inside bucket

lifting type:F-tripod enlarge lifting,T-tripod enlarge lifting,the twin-cylinder lifting,the former top

                         lifting,and double rollover lifting

High efficiency:maximum loading capacity and light weight technology

Standard:synchronize with European and American technology and modular design





Product description of foton ROWOR 10 ton tipper truck



Basic information:
Product Namefoton ROWOR tipper truck
Product ModelBJ3165DJPHA-1
Drive type4*2
Gross weight16000kgs
Rated load8055kgs
Kerb weight7815kgs
Wheelbase3900mm
Overall size:7265x2495x3060mm
Front trend1940mm
Rear trend1851mm
Approach/Departure Angle29/18(°)
Cargo body:
Length4800mm
Width2300mm
Height800mm
TypeRear Dump type
Engine:
EngineYC6J160-42
Displacement6500ml
Power118kw
Horsepower160hp
Fuel typeDiesel
Emission standardEuro 4
Gearbox:
Gearbox 10JS90A/Fast
Forward gear/Reverse gear10/2
Tyre:
Tyre no.6
Tyre specification10.00R20
Oil box:
oil box capacity200L





Product pictures of foton ROWOR 10 ton tipper truck

















Similar Products:



Production equipment



WHY CHOOSE US?

  • Experience
  • 10 years experience of production,sales,research and development in the field of special trucks.
  • Specialization
  • OEM&ODM is available,we can produce according to your demand, the material,the size, the color and the logo is optional for you.
  • Good Quality
  • has solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system and passed the ISO9001-2008 and the 3C (China Compulsory Certification),with SGS,BV certifcate as well.
  • Chassis supply
  • we have a very good long term cooperation relationship with chassis manufacturer,such as DONGFENG,FOTON,SINOTRUCK,SHACMAN,IVECO,FAW,HINO,CAMC,NORTH-BENZ,etc.
  • Production supply capacity
  • Company Scale: More than 3000 employees with 1000 acres factory, total asset 2 billion.
  • We manufacture the truck as soon as possible once your order confirmed. And for the stock, we can delivery it immediately.

  • Our services
  • 1. we can send our technician to arrive the customer's country to provide the service and also we can train customer‘s workers for free.
  • 2. free consultation forever. When you meet small problems, professional advices can help you to solve them soon.

    3. One year free cost warranty.

  • 4. Spare parts forever. When you need spare parts, we can send them to you immediately.

Our customers:

About us

Hubei Changjie Special Automobile Co., Ltd. , is a professional manufacturer of special automobiles for 10 years. Our company has independent export authority, and has a lot of overseas clients.

Our leading products include more than 8 series and 100 types of trucks such as water trucks, tank trucks, garbage trucks, fecal suction trucks, sewage suction trucks, dump trucks, van trucks, semi-trailers, wrecker trucks, trucks with cranes, high-altitude operation trucks, training trucks, bulk cement trucks, chemical liquid trucks, fire engines, truck fittings, cement mixers and tractors. At the same time, we deal with wholesale chassis.

Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation. What's more, we have obtained ISO9001 and CCC certificates (China Compulsory Certification).

Our survival is based on the quality.Credit standing is the guarantee of our success. We will endeavor to treat customers honestly, managing flexibly, guaranteeing high quality but low price, and keeping high efficiency. We promise that all the products that are adapted and sold by us can get one-year services and maintenance for the life.









Contact us for any foton ROWOR 10 ton tipper truck
