diagram of concrete cement mixer truck

FOB Reference Price:Get Latest Price
$70,000.00 - $80,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Weight:
25000
Condition:
New
Place of Origin:
Hubei, China
Brand Name:
DONGFENG
Dimension(L*W*H):
8840*2500*3930mm
Certification:
3C,ISO,BV,SGS
tank material:
Q345
tank material thickness:
5mm
tank head thickness:
6mm
tank capacity:
8 cubic meters
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude with wax, large size transported by RO-RO ship or Bulk ship,small size can be put into a 20GP,40GP or 40HQ.
Port
shanghai
Lead Time :
30 working days

diagram of concrete cement mixer truck

Our company is a professional CONCRETE MIXER TRUCK manufacturer for 10 years

we can provide CONCRETE MIXER TRUCK from 3m3 to 16m3

Any questions,contact me without hesitation on 135-9782-6887





Product features

1, mixing drum and mixer blade using special wear-resisting material Q345/16Mn

2, material of blowpit and feed hopper scaleboard is just the same as the mixing drum

3, humanizing operating system,connecting rod operation,concise safe and reliable

4, using imported brand-name hydraulic system

5, flushing water back control

6, product with quick discharging, no residual



SystemItemReference Data
Parameters of mixing drumagitation volume (m3)8
charging rate (m3/min)≥2.8
discharging rate (m3/min)≥1.2
residual rate  (%)≤0.5
rotating speed of mixing drum  (rpm)0~17
Driving systemspeed reducermade in Italy by PMP
hydraulic pumpmade in Italy by PMP
hydraulic motormade in Italy by PMP
radiatormade in China
Water supply water tank volume (L)450
type of water supplyair pressure water supply
Control systemcontrol modeconnecting rod control





Product description

Product NameDongfeng 8 cubic meters concrete mixer truck
Product Modeldongfeng
Main parametersOverall size(L*W*H)8840X2500X3930mm
Gross weight25000kgs
Rated capacity1805,11870kgs
Curb weight13000kgs
Approaching/Departure Angle30/18(°)
Front/Rear suspension1460/2380mm
Max.speed80km/h
ChassisChassis BrandDongfeng
Chassis modelDFL5250GJBA
Drive type6X4, LHD/RHD
Fuel TypeDiesel
Tire Specification11.00-20,11.00R20
12.00-20,12.00R20
Tire No.10
Wheelbase3650+1350mm
3800+1350mm,4000+1350mm
Alex No.3
Leaf Spring No.8/12,9/10,9/13
GearboxShaanxi teeth 9 speed
Front trend1986,2027mm
Rear trend1860/1860,1820/1820mm
EngineManufacturerDongfeng Engine
ModelISLe340 30
Horse Power340HP
Displacement/Power8900ml/250kw
Emission standardEuro 3/Euro 4





Product pictures









Detailed picture:









Similar Products:



Production workshop



Production equipment



WHY CHOOSE US?

  • Experience
  • 10 years experience of production,sales,research and development in the field of special trucks.
  • Specialization
  • OEM&ODM is available,we can produce according to your demand, the material,the size, the color and the logo is optional for you.
  • Good Quality
  • has solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system and passed the ISO9001-2008 and the 3C (China Compulsory Certification),with SGS,BV certifcate as well.
  • Chassis supply
  • we have a very good long term cooperation relationship with chassis manufacturer,such as DONGFENG,FOTON,SINOTRUCK,SHACMAN,IVECO,FAW,HINO,CAMC,NORTH-BENZ,ect.
  • Production supply capacity
  • Company Scale: More than 3000 employees with 1000 acres factory, total asset 2 billion.
  • We manufacture the truck as soon as possible once your order confirmed. And for the stock, we can delivery it immediately.

  • Our services
  • 1. we can send our technician to arrive the customer's country to provide the service and also we can train customer‘s workers for free.
  • 2. free consultation forever. When you meet small problems, professional advices can help you to solve them soon.

    3. One year free cost warranty.

  • 4. Spare parts forever. When you need spare parts, we can send them to you immediately.

Our customers:

About us

Hubei Changjie Special Automobile Co., Ltd. , is a professional manufacturer of special automobiles for 10 years. Our company has independent export authority, and has a lot of overseas clients.

Our leading products include more than 8 series and 100 types of trucks such as water trucks, tank trucks, garbage trucks, fecal suction trucks, sewage suction trucks, dump trucks, van trucks, semi-trailers, wrecker trucks, trucks with cranes, high-altitude operation trucks, training trucks, bulk cement trucks, chemical liquid trucks, fire engines, truck fittings, cement mixers and tractors. At the same time, we deal with wholesale chassis.

Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation. What's more, we have obtained ISO9001 and CCC certificates (China Compulsory Certification).

Our survival is based on the quality.Credit standing is the guarantee of our success. We will endeavor to treat customers honestly, managing flexibly, guaranteeing high quality but low price, and keeping high efficiency. We promise that all the products that are adapted and sold by us can get one-year services and maintenance for the life.
