Hot selling good quality cheap price 4x2 dongfeng 5 ton water truck for drinking water

FOB Reference Price:Get Latest Price
$15,000.00 - $20,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Sprinkling Area (m):
12 - 16m
Engine Capacity:
< 4L
Gross Vehicle Weight:
7300
Dimensions (L x W x H) (mm):
5990*1960*2380mm
Drive Wheel:
4x2
Fuel:
Diesel
Transmission Type:
Manual
Condition:
New
Emission Standard:
Euro 4
Tank Volume:
5001 - 10000L
Brand Name:
dongfeng
Place of Origin:
Hubei, China
Model Number:
DFA1070SJ35D6
Certification:
3C, ISO,SGS,BV
tank material:
Q235 carbon steel
tank thickness:
4mm
tank size:
3400*1600*1100mm
water tank volume:
5 ton
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
One Year
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude with wax, large size transported by RO-RO ship or Bulk ship,small size can be put into a 20GP,40GP or 40HQ.
Port
shanghai
Lead Time :
30 working days

Hot selling good quality cheap price 4x2 dongfeng 5 ton

water truck for drinking water



Our company is a professional WATER TRUCK manufacturer for 10 years

we can provide water truck from 3ton to 40ton

Any questions,contact me without hesitation on 135-9782-6887




Product features

Tank material:carbon steel,stainless steel

Tank shape:round square,oval,round

Pump:self-priming pump,centrifugal pump

High efficiency:maximum loading capacity and light weight technology

Standard:synchronize with European and American technology and modular design





More Details:



1.basic component :antirust tank, connecting device, special self suction sprinkler pump, pipeline,
spray outlet, work platform.



2. tank body adopts high quality carbon steel plate produced in WISCO, using large machine molding, junction of the tank head and body using advanced arc welding process.


3.standard configuration: The water truck installed the sprinkler(front, rear,and side),and the

Sprinking length exceed 14 meters,the rear platform with water cannon(range be bigger than 28

meters), Installed the CLW Brand water Pump ,with virescence sprinkler gun, the sprinkler gun can

rotate 360 degrees,also can be adjusted into mist, range ≥ 15m, vertical suction process 7M.



4.functional use: widely used in sprinkler, spray, cooling, dust removal, flushing dust booties,

spray pesticides,motor pump station,etc.



5.optional configuration: medicine wheel, drug pump, tank anti-corrosion rust-proof, multi-directional water joints,electro magnetic.







Product description

Vehicle main technical information:
Product NameDongfeng 4x2 5 ton water truck
Product ModelDongfeng
Water tank size(mm)3400*1600*1100(length*long axis*minor axis)
Overall size(L*W*H)5990×1960×2380mm
Gross weight7300kgs
Rated capacity4020,3955kgs
Curb weight3150kgs
Approaching/Departure Angle16/13(°)
Front/Rear suspension1032/1658mm
Max.speed95km/h
Chassis Parameters:
Chassis BrandDongfeng
Chassis modelDFA1070SJ35D6
Drive type4X2, LHD/RHD
Fuel TypeDiesel
Tire Specification7.00R16,7.00-16
Tire No.6
Wheelbase3300mm
Alex No.2
Leaf Spring No.8/9+5,6/8+4
Front trend1506,1404mm
Rear trend1466,1458mm
Passengers in cab2 or 3
Axle loading2920/4380
Engine Parameters:
ManufacturerKunming Yunnei Power Co.,Ltd.
ModelYN33CRD2
Horse Power102HP
Displacement/Power3298ml/75kw
Emission standardEuro 4





Product pictures











Structure drawing:



Similar Products:



Water truck production line









Production workshop



Production equipment



WHY CHOOSE US?

  • Experience
  • 10 years experience of production,sales,research and development in the field of special trucks.
  • Specialization
  • OEM&ODM is available,we can produce according to your demand, the material,the size, the color and the logo is optional for you.
  • Good Quality
  • has solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system and passed the ISO9001-2008 and the 3C (China Compulsory Certification),with SGS,BV certifcate as well.
  • Chassis supply
  • we have a very good long term cooperation relationship with chassis manufacturer,such as DONGFENG,FOTON,SINOTRUCK,SHACMAN,IVECO,FAW,HINO,CAMC,NORTH-BENZ,etc.
  • Production supply capacity
  • Company Scale: More than 3000 employees with 1000 acres factory, total asset 2 billion.
  • We manufacture the truck as soon as possible once your order confirmed. And for the stock, we can delivery it immediately.
  •
  • Our services
  • 1. we can send our technician to arrive the customer's country to provide the service and also we can train customer‘s workers for free.
  • 2. free consultation forever. When you meet small problems, professional advices can help you to solve them soon.

    3. One year free cost warranty.

  • 4. Spare parts forever. When you need spare parts, we can send them to you immediately.

Our customers:

About us

Hubei Changjie Special Automobile Co., Ltd. , is a professional manufacturer of special automobiles for 10 years. Our company has independent export authority, and has a lot of overseas clients.

Our leading products include more than 8 series and 100 types of trucks such as water trucks, tank trucks, garbage trucks, fecal suction trucks, sewage suction trucks, dump trucks, van trucks, semi-trailers, wrecker trucks, trucks with cranes, high-altitude operation trucks, training trucks, bulk cement trucks, chemical liquid trucks, fire engines, truck fittings, cement mixers and tractors. At the same time, we deal with wholesale chassis.

Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation. What's more, we have obtained ISO9001 and CCC certificates (China Compulsory Certification).

Our survival is based on the quality.Credit standing is the guarantee of our success. We will endeavor to treat customers honestly, managing flexibly, guaranteeing high quality but low price, and keeping high efficiency. We promise that all the products that are adapted and sold by us can get one-year services and maintenance for the life.
