China wholesale High Quality 4x2 hook lift garbage truck with 10m3 detachable garbage collection compartment

FOB Reference Price:Get Latest Price
$27,500.00 - $38,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Engine Capacity:
4500ml
Gross Vehicle Weight:
12490
Condition:
New
Drive Wheel:
4x2
Type:
hooklift
Transmission Type:
Manual
Emission Standard:
Euro 3
Fuel Type:
Diesel
Size:
7300*2470*2900mm
Place of Origin:
Hubei, China
Brand Name:
Dongfeng
Model Number:
Tianjin
Certification:
3C,ISO,BV,SGS
Curb weight:
5495kg
garbage collection box volume:
10-12m3
garbage collection box material:
carbon steel Q235
side plate thickness:
3mm
bottom plate thickness:
4mm
truck color:
white or optional
Hook lifting system:
hydraulic system
Control system:
operating handles and remote control
Self-unloading or not:
yes
Recommended matching garbage box No.:
10~20 garbage collection boxes
Volume:
10001 - 15000L
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude with wax, large size transported by RO-RO ship or Bulk ship,small size can be put into a 20GP,40GP or 40HQ.
Port
shanghai
Lead Time :
25~30 working days

 4x2 hook lift garbage truck with 10m3 garbage collection box

Product Description



Biggest advantages of hooklift garbage truck:



1. This is a kind type of very high efficient and useful garbage truck,with vehicle chassis and upper structure garbage collecting boxes. The highest efficient point is that you only need one garbage truck and can transport and place 10~20 and even more garbage collecting boxes in the whole community or other place where need garbage collecting boxes;


2. More special advantage is that this type hooklift garbage truck with two kind of functions: when garbage collecting box is full, the truck can hook lift the garbage boxes and transport them to the garbage station; Also, when arriving the station, it can directly self-unloading garbage by controling to lock the garbage box;


3. Control system
Available in two type: operating handle on the side of vehicle and remote control in the driving cabin;


4. For garbage collecting boxes, we can provide wholesale and price is really cheap,about 500USD~1,200USD per set according to size. For mass production, short production cycle.

Product Show


Vehicle main technical information:
Product NameDongfeng Tianjin hook lift garbage truck
Vehicle ModelDongfeng
Overall size(L*W*H)7300×2470×2900mm
Gross weight12490kgs
Rated capacity6800kgs
Curb weight5495kgs
Approaching/Departure Angle20/6(°)
Front/Rear suspension1430/1370,1430/1670mm
Max.speed90km/h
Chassis Parameters:
Chassis BrandDongfeng
Chassis modelDFL112
Fuel Typediesel
Tire Specification9.00-20,9.00R20,10.00-20,10.00R20
Tire No.6
Wheelbase4200,4500mm
Alex No.2
Leaf Spring No.7/9+6,8/10+8
Front trend1880mm
Rear trend1800,1860mm
Passengers in cab3
Axle loading 4280/8210
Engine Parameters:
ManufacturerDongfeng Engine
ModelCummins
Horse Power180HP
Displacement/Power4500ml/132kw
Emission standardEuro 3
Related Products





Garbage Collecting Boxes Detail:

Hydraulic control,covers and rear gate:



Company Information

Certifications



Our Services

Excellent Pre-sale Service
1. According to your specification request, provide the best price for you.
2. After you confirmed the specification and price, our engineers will draw a Official Drawing for you confirm.
3. After our Finance Department confirmed your deposit or Irrevocable L/C, we will start manufacture the products for you.
4. Update the progress of production to you in time, to help you know your order details progress.
5. After the product manufacture finished, if you need, we will arrange shipping for you. With our professional skill, you just need to pick your products up at the destination place, and don’t need to worry about the shipping at all.

Outstanding After-sale Service
1. If you have any questions when you use our products, please tell us, we will help you solve the problems in time.
2. If any spare parts have problem after you used it, we can provide it for you, help you solve the problem if anything affect your business.
3. We can also provide engineer to your local place if you need. You just need to bear the Airplane ticket, and accommodation cost.
4. Other relevant service you request.

1. 12 months guarantee term.
2. Small order accepted.
3. Professional technic support.
4. After-sale service.
5. Suit your needs excellence by design.
